KMLOCfg | KMLOFax | KMLOVoice   A KDE-based utility to configure modems of the ELSA MicroLink Office family

KMLOCfg is a KDE-based utility to configure modems of the ELSA MicroLink Office family. This family consists of the MicroLink Office, the MicroLink Office II and the MicroLink ISDN Office. The modems of the ELSA MicroLink Office family have a flash memory for fax and voice reception without PC. They can store up to 70 facsimile pages and up to 15 minutes of voice messages. For more information about these modems visit the Home Page of the Neue ELSA GmbH, please. KMLOCfg for KDE 1.x 2000-04-04: Version 0.1.1 available! Changes against version 0.1.0: Fixed a bug that may cause the serial communication to hang. KMLOCfg for KDE 2.x 2002-04-07: New version 2.0-pre5 available! Changes against version 2.0-pre4: USB support for the MicroLink ISDN Office. Some bugs have been fixed. KMLOCfg for KDE 3.x  2003-05-18: New version 3.0 final available! Changes against version 3.0-pre1: The compatiblity with the GNU C compiler version 3.x has been improved.		Contents  · Requirements  · Download  · Roadmap  · Technical tips  · Related projects  · Legal information

KMLOCfg is designed to work on UNIX^® systems with the K Desktop Environment (KDE). The following things have to be installed on your system in order to build and use KMLOCfg:

KMLOCfg for KDE 1.x

• Qt^TM GUI toolkit version 1.41 or better (not 2.x, not 3.x).
  Visit Trolltech for more information about Qt^TM.
• K Desktop Environment version 1.x (not 2.x, not 3.x).
  You can get the latest 1.x version from The KDE Home Page.

KMLOCfg for KDE 2.x

• Qt^TM GUI toolkit version 2.2.1 or better (not 1.x, not 3.x).
  Visit Trolltech for more information about Qt^TM.
• K Desktop Environment version 2.x (not 1.x, not 3.x).
  You can get the latest 2.x version from The KDE Home Page.

KMLOCfg for KDE 3.x

• Qt^TM GUI toolkit version 3.0.3 or better (not 1.x, not 2.x).
  Visit Trolltech for more information about Qt^TM.
• K Desktop Environment version 3.x (not 1.x, not 2.x).
  You can get the latest 3.x version from The KDE Home Page.

KMLOCfg for KDE 1.x

	Name	Size	Description
	kmlocfg-0.1.0.lsm	539 Bytes	Linux® Software Map
	kmlocfg-0.1.0.tar.gz	255,834 Bytes	Gzipped Source Archive
	kmlocfg-0.1.1.lsm	542 Bytes	Linux® Software Map
	kmlocfg-0.1.1.tar.gz	254,627 Bytes	Gzipped Source Archive

KMLOCfg for KDE 2.x

	Name	Size	Description
	kmlocfg-2.0-pre4.lsm	554 Bytes	Linux® Software Map
	kmlocfg-2.0-pre4.tar.gz	424,626 Bytes	Gzipped Source Archive
	kmlocfg-2.0-pre5.lsm	554 Bytes	Linux® Software Map
	kmlocfg-2.0-pre5.tar.gz	463,607 Bytes	Gzipped Source Archive

KMLOCfg for KDE 3.x

	Name	Size	Description
	kmlocfg-3.0-pre1.lsm	552 Bytes	Linux® Software Map
	kmlocfg-3.0-pre1.tar.gz	463,603 Bytes	Gzipped Source Archive
	kmlocfg-3.0.lsm	547 Bytes	Linux® Software Map
	kmlocfg-3.0.tar.gz	650,897 Bytes	Gzipped Source Archive

Plannings for future releases

The development will be focused on the KDE 3 versions now.

The ELSA MicroLink ISDN Office and Linux^®

Connection to an internet service provider

The MicroLink ISDN Office is an ISDN terminaladaptor with serial and USB interface. It behaves like a normal analog modem with extended AT command set. Thus the connection to an internet service provider can be done like it would be a modem. If your provider doesn't support the protocol X.75 on the B-channel, which can be noticed by the message "NO CARRIER" after dialing, you can try the modem command AT$IBP=HDLCP for modem initialization.

The USB interface

The MicroLink ISDN Office conforms to the Universal Serial Bus Communication Device Class Abstract Control Model (USB CDC ACM). Thus it can be used also under Linux^® both with the serial interface and through the USB interface.

Under Linux^® with kernel version 2.4 it is done with the ACM driver. The following kernel modules have to be loaded:

• usbcore.o (CONFIG_USB=m)
• usb-uhci.o (CONFIG_USB_UHCI=m) or uhci.o (CONFIG_USB_UHCI_ALT=m) or usb-ohci.o (CONFIG_USB_OHCI=m)
• acm.o (CONFIG_USB_ACM=m)

The MicroLink ISDN Office then can be accessed over the special file /dev/usb/ttyACM0. If this file does not exist, you can create it with mknod /dev/usb/ttyACM0 c 166 0. Please consider the access rights of the users.

KMLOFax

A KDE-based facsimile utility for the ELSA MicroLink Office modem.

KMLOVoice

A KDE-based voice message utility for the ELSA MicroLink Office modem.

MLO2HFAX

A utility for the ELSA MicroLink Office modem with HylaFAX^TM.

MLO2mgetty

A utility for the ELSA MicroLink Office modem with mgetty+sendfax.

MLO2TIFF

A command line facsimile utility for the ELSA MicroLink Office modem.

License

KMLOCfg is free software and is distributed under the terms of the GNU General Public License (GPL). No warranty is granted for any kind of damages which may be caused by installation or use of this software!
